Quick answer

Turn off sensitive and 240V loads, stop adding load, and record which generator receptacles and transferred circuits work. Check only visible external controls, the exact voltage-selector position, output breaker state, cord and connector damage while de-energized, transfer indicators, and load-management status. Do not open the generator, inlet, transfer switch, or panel. Repeated trips, abnormal voltage, heat, odor, arcing, or partial building power require qualified electrical and generator service.

Symptom boundary worksheet

Locate the partial-power boundary without opening live equipment

Choose the closest observation after the generator is in its approved location and every load has been removed. The worksheet keeps the next check outside guarded engine, fuel, alternator, transfer and panel work.

Stop boundary

Keep 240V and sensitive loads off

A hot leg may be unavailable in the cord, inlet, transfer, breaker, panel, or generator path.

  1. Record which circuits work.
  2. Photograph external selector and breaker states.
  3. Use qualified electrical and generator diagnosis.

Never troubleshoot a combustion generator indoors. Do not bypass a breaker, GFCI, low-oil, carbon-monoxide or controller shutdown, and do not open energized generator or transfer equipment.

System type120/240V split phase
SymptomSome 120V circuits, no 240V loads
First actionRemove sensitive and 240V loads
Live equipmentQualified service only
DECISION PATHUse the evidence in the right order01STEP 1Map the symptom withoutopening energizedequipment02STEP 2Check only the externalconfiguration andconnection03STEP 3Leave breaker poles,transfer contacts,conductors,04STEP 4Return loads only afterboth legs andline-to-line
Follow the decision in order; a later check cannot repair a failed earlier check.

Map the symptom without opening energized equipment

Record whether one generator receptacle is affected, whether both 120V legs are available at the generator according to approved indicators or tests, whether the condition begins after the cord and inlet, and which transferred circuits remain available. Photograph external breaker, selector, transfer, and controller indications.

Turn off 240V motors, pumps, HVAC, ranges, water heaters, and sensitive electronics until the complete source is verified. A 240V load can receive abnormal or zero line-to-line voltage when one hot leg is missing. Do not use working 120V circuits as proof that the system is safe.

Partial generator power boundaries
ObservationPossible boundarySafe response
One receptacle section affectedReceptacle or branch protectionDisconnect loads and use manual-approved checks
Generator output normal, house partialCord, inlet, transfer or panel pathQualified building-system review
All 240V loads failMissing leg or wrong selector configurationKeep 240V loads off
Heat, odor, arcing or repeated tripDamaged high-energy connectionShut down and keep out of service

Check only the external configuration and connection labels

With loads removed and the system de-energized as required by the manuals, inspect the cord, L14-30 or 14-50 endpoints, locking engagement, visible pins, cable jacket, and strain relief. Confirm the generator output breaker is fully reset only if the manual permits and the voltage selector is in the required 120/240V position.

Confirm that the cord and inlet carry both hot conductors, neutral, and equipment ground for the intended split-phase path. A 120V-only source or adapter cannot energize a true 120/240V panel. Do not bridge legs to make both sides appear live because multiwire and 240V circuits can be damaged or left unsafe.

BEFORE YOU ACTKeep four checkpoints visibleREAD120/240V split phaseDo not infer missing data.CALCULATESome 120V circuits,no 240V loadsDo not infer missing data.VERIFYRemove sensitive and240V loadsDo not infer missing data.CONFIRM4 primary referencesOpen and verify the source.
Keep equipment labels, calculations, system limits, and primary references separate.

Leave breaker poles, transfer contacts, conductors, and windings to qualified diagnosis

A failed breaker pole, loose or overheated termination, damaged cord conductor, inlet fault, transfer contact, selector, winding connection, or alternator fault can create partial power. Confirming those possibilities can expose utility and generator sources even when one source appears off.

Use a qualified electrician for the inlet, transfer, and panel path and model-specific generator service for source output. Provide the symptom map, equipment labels, selector position, breaker and transfer state, connected loads, weather, event timing, and any fault history.

Return loads only after both legs and line-to-line output are verified

Qualified commissioning should verify acceptable line-to-neutral voltage on both legs, line-to-line voltage, frequency, polarity, neutral and grounding arrangement, transfer operation, per-leg loading, and protection. Test with controlled loads before restoring motors and sensitive equipment.

Balance 120V loads within generator per-leg limits and document the approved selector, breaker, cord, transfer, and load sequence. Stop immediately if partial power, abnormal voltage, or heat returns.

Frequently asked questions

Common questions

Why does only half my house work on generator power?

One split-phase leg may be unavailable somewhere in the generator, breaker, cord, inlet, transfer, or panel path. Keep 240V loads off and obtain qualified diagnosis.

Can I connect both panel legs to one 120V generator output?

Do not improvise that arrangement. It can affect multiwire circuits, 240V loads, transfer equipment, protection, and conductor loading. Use an approved design.

Could the generator voltage selector cause partial power?

Yes, an incorrect model-specific selector position can change available receptacles or winding configuration. Change it only through the exact unloaded procedure.

Can I measure both legs myself?

Only a person qualified for the equipment and electrical hazard should perform live measurements using an approved procedure and suitable instruments.

Primary references

CordFind summarizes connector specifications and public safety guidance. Always follow the instructions supplied with your equipment.
